Engineering Tomorrow’s Solutions
Polwax GSM Temperature Datalogger offers precision, reliability, and advanced features tailored to meet the demands of modern industries. With GSM connectivity, it bridges the gap between local monitoring and global accessibility, ensuring that temperature data is always within reach.
GSM Temperature Datalogger
Polwax CLIMA
- Real-time Data Monitoring
- GSM Data Communication
- 3.5”Touch Screen Display
- Polwax CloudDASH360 cloud dashboard
- High speed Sampling
- Warranty : 2 Years
The Polwax GSM Temperature Datalogger is an advanced solution for real-time temperature monitoring with GSM communication capabilities. Designed for versatility and reliability, this datalogger provides precise temperature data from critical environments while allowing seamless data transmission via GSM networks.
With its robust build, intuitive interface, and compatibility with Polwax CloudDASH360, it is ideal for industries requiring continuous monitoring and data management.Polwax GSM Temperature Datalogger offers precision, reliability, and advanced features tailored to meet the demands of modern industries.
Product Overview
Polwax GSM Temperature Dataloggers are advanced monitoring devices designed for precise measurement and data logging of temperature and humidity. These dataloggers are available in multiple models to suit different requirements, offering one, two, or four-channel configurations. With high-accuracy sensors, they can measure temperature ranges from -100°C to +400°C using external Pt100 sensors and integrated sensors for temperature (-40°C to +70°C) and humidity (0-100% RH). Their versatility is further enhanced with additional input options, including RTD, Thermocouple, and 4-20mA signals, making them ideal for diverse industrial applications.
Equipped with GSM Dataloggers communication, these devices allow seamless remote data transmission to cloud platforms like POLWAX CloudDASH360, enabling real-time monitoring and management through web and mobile apps. The dataloggers feature a 3.5-inch TFT color touch screen for easy configuration and secure access via password protection. Built with robust IP65-rated enclosures, they are suitable for use in harsh environments and offer flexible wall or table mounting options. The Polwax GSM Temperature Datalogger is an advanced solution for remote temperature monitoring, equipped with GSM connectivity to transmit real-time temperature data to mobile phones or email. Ideal for environments where direct monitoring is challenging, it provides reliable and continuous tracking, ensuring that temperature-sensitive items or processes are closely monitored.
Polwax GSM Temperature Dataloggers find extensive applications in industries such as cold chain logistics, pharmaceuticals, HVAC systems, agriculture, and cleanrooms. These devices ensure the reliability and integrity of temperature and humidity-sensitive processes, with the added convenience of desktop software and optional cloud integration. Certified for CE, RoHS, and EN12830 standards, Polwax dataloggers deliver unmatched reliability, accuracy, and ease of use, making them the preferred choice for precise environmental monitoring.
Find More
Technical Data
Media compatibility
Air, non combustible, non corrosive gases
Model No
Clima CG100T
Clima CG200T
Clima CG400T
Clima CG200TH
Clima CG400TH
Part Code
0399 2111
0399 2211
0399 2411
0399 2221
0399 2421
No of Channels
1
2
4
2
4
Input Parameters
Temperature
Temperature
Temperature
Temperature - Humidity
Temperature - Humidity
Measuring Ranges
External Sensor
Pt100(-100 to 400 °C)
External Sensor
Pt100(-100 to 400 °C)
External Sensor
Pt100(-100 to 400 °C)
Integrated Sensor
Temperature:-40 to +70 °C
Humidity : 0 - 100% RH
External Sensor
Temperature:-40 to +70 °C
Humidity : 0 - 100% RH
Other Inputs
Temp + RH / RTD pt100 / Thermocouple / 4-20mA / 0-20mA / 0-10V /0-5V / 0-1V / Digital
Resolution
Temp: 0.01 / RH: 0.01
Sensor Accuracy
Temperature : ±0.3°C / Humidity : ±2% (at 5-95%)
Communications
GSM
Password Protection
Access to configuration is allowed only after the user has entered a password
Display
TFT color 3.5” touch screen display
Filename
Name tag, prexed with date/time
Thermocouple Types
K, J, N, R, S, T
Sensor Filter
ABS ( standard ) / Ceramic / SS ( optional )
Mounting
Wall Mount / Table Mount
Protection Class
IP65
Power Supply
24V DC ( Adaptor)
Operating
Temperature
10°C to 60°C
Storage Temperature
10°C to 60°C
Data Monitoring Desktop Software
POLWAX_P-View (Suitable for Win10 / Win10Pro)
Report Format
.PDF/.CSV/.XLSX
Cloud Dashboard (Optional)
POLWAX CloudDASH360 - Web App / Mobile App ( Android + iOS )
Language
English
Certification
CE , RoHS , EN12830
Scope Of Supply
Calibration Certificate , Instruction Manual , Power Adaptor , Antenna
Cloud Information for Polwax GSM Temperature Dataloggers
Real-Time Data Synchronization
Polwax GSM Temperature Dataloggers automatically synchronize collected data with the cloud in real-time using GSM connectivity. This eliminates the need for manual data transfers and ensures that the latest readings are always available. Whether you’re monitoring critical temperature and humidity parameters in a remote warehouse or an industrial process, real-time updates allow for immediate insights and quicker decision-making.
Secure and Redundant Data Storage
The dataloggers leverage secure cloud servers to store your data, ensuring its safety and accessibility. Built-in redundancy mechanisms protect your data from potential loss due to hardware failures or other disruptions. All data transmissions to the cloud are encrypted, adhering to stringent industry standards to prevent unauthorized access. Additionally, historical data stored on the cloud enables detailed trend analysis and compliance reporting.
Global Accessibility CloudDASH360
Polwax’s CloudDASH360 platform offers users access to their data anytime, anywhere, through a web browser or mobile application. The user-friendly interface provides comprehensive visualization tools, including graphs, dashboards, and alarm notifications.
The cloud platform also supports multi-user access with role-based permissions, allowing team members to view or manage data based on their responsibilities.
