Engineering Tomorrow’s Solutions

The Polwax Clima offers unmatched accuracy, reliability, and convenience for temperature monitoring in diverse environments. With WiFi connectivity and compatibility with Polwax CloudDASH360, it provides a seamless solution for modern data logging needs.

WiFi Datalogger
Temperature & Humidity
Polwax CLIMA
Part Code Series : 0399
  • Real-time Data Monitoring
  • WiFi Data Communication
  • 3.5”Touch Screen Display
  • Polwax CloudDASH360 cloud dashboard
  • High speed Sampling
  • Warranty : 2 Years

Temperature and humidity are accurately recorded by the WiFi data loggers at customizable intervals, and the measurement values are sent directly via wireless LAN to the Polwax Cloud. A WiFi data logger is instruments which allows measuring and storing the values of certain physical quantities, such as temperature, humidity, pressure, solar radiation, etc.

The Polwax Clima WiFi Temperature Datalogger is a cutting-edge monitoring device designed to deliver precise and reliable temperature tracking. With seamless WiFi connectivity, a robust IP65-rated enclosure, and an intuitive 3.5″ touch screen display, this datalogger is ideal for industrial and commercial environments.  PC the transfer of data from a digital acquisition system to a PC allows storing the measured values even after the internal memory of the acquisition system is full.

Product Overview

The highlights of WiFi Dataloggers CW200 TH Connect include wireless connection, high autonomy, and flexibility for different types of sensors. The value addition is completed by the large display, portability, and simple installation. Mobile device configuration and data downloading are also possible. Temperature and humidity are accurately recorded
by the WiFi Dataloggers at customizable intervals, and the measurement values are sent directly via wireless LAN
to the Polwax Cloud. A WiFi Dataloggers is instruments which allows measuring and storing the values of certain physical quantities, such as temperature, humidity, pressure, solar radiation, etc.
Quick and easy installation: as it is not necessary the laying of cables and conduits, a wireless system is installed much more easily and quickly than a wired system, especially when the components are at a great distance from one another.
Reduction of installation costs: the absence of cables allows a considerable saving in cost of material and labor. Flexibility of the system: the absence of fixed links between the various parts allows moving the system components at any time without problems. Low maintenance: the cables are subject to deterioration over time, the absence of cables reduces the maintenance costs of the system.

Product Information Polwax WiFi Dataloggers. A data recording system is a set of instruments which allows measuring and storing the values of certain physical quantities, such as temperature, humidity, pressure, solar radiation, etc. A data recording system is generally made of Sensors they are placed at the measuring points and convert the values of the physical quantities into electrical analog or digital signals. Acquisition system it reads and logs the electrical signals outgoing from the sensors. If the acquisition system is digital, the acquired values are kept in the system’s internal memory until the memory is full. The Polwax WiFi Datalogger for Temperature and Humidity offers a cutting-edge solution for real-time environmental monitoring. WiFi Dataloggers is designed to provide accurate and reliable readings of both temperature and humidity across a wide range of applications. The datalogger seamlessly integrates with WiFi networks, enabling remote monitoring and data collection from anywhere with internet access.

Find More

Please download our document to see specific data of the service and how we work.

Technical Data

Media compatibility

Air, non combustible, non corrosive gases

Model No

Clima CW100T

Clima CW200T

Clima CW400T

Clima CW200TH

Clima CW400TH

Part Code

0399 1111

0399 1211

0399 1411

0399 1221

0399 1421

No of Channels

1

2

4

2

4

Input Parameters

Temperature

Temperature

Temperature

Temperature - Humidity

Temperature - Humidity

Measuring Ranges

External Sensor
Pt100(-100 to 400 °C)

External Sensor
Pt100(-100 to 400 °C)

External Sensor
Pt100(-100 to 400 °C)

Integrated Sensor
Temperature:-40 to +70 °C
Humidity : 0 - 100% RH

External Sensor
Temperature:-40 to +70 °C
Humidity : 0 - 100% RH

Other Inputs

Temp + RH / RTD pt100 / Thermocouple / 4-20mA / 0-20mA / 0-10V /0-5V / 0-1V / Digital

Resolution

Temp: 0.01 / RH: 0.01

Sensor Accuracy

Temperature : ±0.3°C / Humidity : ±2% (at 5-95%)

Communications

WiFi

Password Protection

Access to configuration is allowed only after the user has entered a password

Display

TFT color 3.5” touch screen display

Filename

Name tag, prexed with date/time

Thermocouple Types

K, J, N, R, S, T

Sensor Filter

ABS ( standard ) / Ceramic / SS ( optional )

Mounting

Wall Mount / Table Mount

Protection Class

IP65

Power Supply

24V DC ( Adaptor)

Operating Temperature

10°C to 60°C

Storage Temperature

10°C to 60°C

Data Monitoring Desktop Software

POLWAX_P-View (Suitable for Win10 / Win10Pro)

Report Format

.PDF/.CSV/.XLSX

Cloud Dashboard (Optional)

POLWAX CloudDASH360 - Web App / Mobile App ( Android + iOS )

Language

English

Certification

CE , RoHS , EN12830

Scope Of Supply

Calibration Certificate , Instruction Manual , Power Adaptor , Antenna

Cloud Information Polwax WiFi data loggers

Cloud

The base units equipped with Ethernet, Wi-Fi and GSM/3G connectivity can automatically send, at regular intervals, the data to an HTTP server, and in particular to the Polwax portal “www.polwax.cloud”. This allows you to view the data from anywhere in the world, even by using mobile devices (tablet, smart phone, notebook), simply having an Internet connection ,using a web browser. The data sending interval is configurable.

Configuration

The data logger equipped with LCD and keyboard can be also configured via the front keyboard. The access to the configuration parameters of the data logger via keyboard is password protected. There are two different passwords one for the use of the data logger as operator (access to some settings only) and one for the use as administrator
(access to all the configuration parameters).

Internal clock

The internal clock of each data logger is continuously synchronized with the clock of the base unit, thereby eliminating any problems due to the drift of the data logger clock. This ensures that the data loggers of the system have all the same time, feature particularly useful if you want to compare the measures acquired by various data loggers at the same time.

Applications

Documents

Please download our document to see specific data of the service and how we work.
